Main motor power | 55kW (75HP) |
Main fly wheel diameter (mm) | Φ630 |
Cut width (mm) | 40 |
Cut depth (m) | Max.4.2 |
Water consumption (L/min) | 25 |
Operating water pressure (Mpa) | >0.2 |
Arm length (mm) | 5100/6100 |
Diamond saw belt length (m) | 11.4 |
Saw belt linear velocith (m/s) | 0~16 |
Rail length (m) | 2.8*8 sections |
Guide rail weight (kg/Section) | 310 |
Total weight (kg) | 3800/3920 |
